Features

  • PREMIUM SECURITY: High-quality metal construction provides strength where it counts; Grade 2/AAA rating offers trusted security and durability for residential and light commercial applications
  • INNOVATIVE DESIGN: Flex-locking, use interior switch to change between unlocked or automatic re-locking modes; providing flexibility, security and peace of mind; exit by simply turning door handle
  • KEYLESS CONVENIENCE: Use 2 pre-programmed codes for easy setup out of the box; assign up to 19 codes for trusted friends and family to experience convenient access, keyless entry and security
  • Certified Commercial Grade 2
  • WARRANTY: Limited lifetime mechanical and finish warranty and 3-year electronics warranty, see Schlage warranty for full details
  • EASY INSTALL: Install in minutes with just a screwdriver, no hardwiring required; fits standard doors with 1-3/8 in to 1-3/4 in door thickness and 2-3/8 in or 2-3/4 in backset
  • SECURE KEYPAD ACCESS: Durable, silicone-coated numbers illuminate when pressed, making it easy to enter your code in the dark
  • BATTERY POWERED: Deadbolt operates with included 9V battery; avoid lockouts with dedicated low-battery indicator; get up to 2 years of battery life with typical use

Specifications

Keying5-pin tumbler C keyway with one nickel silver key
Codes2 pre-set unique 4-digit access codes, storage of up to 19 access codes
Battery Cell TypeUses 1 9V battery
Warranty3-Year Electronics Warranty; Limited Lifetime Mechanical and Finish Warranty
Operating TemperaturesOperating Temperatures: Outside escutcheon: -35C to 66C,Inside escutcheon: -10C to 50C
Exterior Dimensions3.01" x 6.84" x 6.85"
Backset (in)Universal latch standard, fits either 2-3/8 in. (60mm) or 2-3/4 in. (70mm) backsets
Door Thickness1-3/8 in. to 1-3/4 in. (35mm-44mm) standard
Certifications ANSI/BHMA A156.2-2011 Grade 2
